Autonics E40S6-500-3-T-24 (500P/R) Rotary Encoder
|Shaft outer diameter||Ø6mm|
|Max. response frequency||300kHz|
|Max. allowable revolution||5000rpm|
|Starting torque||Max. 40gf.cm(max. 0.00392N.m)|
|Output phase||A, B, Z|
|Control output||Totem pole|
|Power supply||12-24VDC ±5%(ripple P-P: max. 5%)|
|Connection type||Radial cable type|
|Environment_Ambient temperature||-10 to 70℃, storage: -25 to 85℃|
|Environment_Ambient humidity||35 to 85% RH, storage: 35 to 90% RH|
|Accessories||Ø6mm coupling standard, Ø8mm coupling(sold separately)|
※Make sure that max. response revolution should be lower than or equal to max. allowable revolution when selecting the resolution.
[Max. response revolution (rpm) = Max. response frequency/Resolution × 60sec]
※The weight includes packaging. The weight in parenthesis is for unit only.
※Environment resistance is rated at no freezing or condensation.
