Wire type and powerDC 3-wire type 12-24VDC
Sensing side diameterM18
Sensing distance8mm
Standard sensing target50×50×1mm(iron)
Response frequency50Hz
Current specificationCurrent consumption: Max.15mA
Control outputPNP Normally Open
MaterialPolyamide 6
Protection structureIP66
Environment_Ambient temperature-25 to 70℃, storage: -30 to 80℃
Environment_Ambient humidity35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance)Max. 20% of sensing distance
WeightApprox. 88g(approx. 76g)

※The response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
※The weight includes packaging. The weight in parenthesis is for unit only.
※The temperature or humidity mentioned in Environment indicates a non freezing or condensation.
